Pumptec M9253F Motor Only Replaces the Old M53 B4CPM-164
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Brand | Pumptec |
| MPN | M9253F |
| Country/Region Of Manufacture | United States |
| Equipment Type | Pump/Sprayer |
Pumptec: M9253F Motor with no mounting base or bridge rectifier AMETEK, 1/4HP, 120V, 34FR, OPEN, USED WITH 205 AND 207 HEADS M9253F No base plate or rectifier Does not include the Cam Bearing that mounts between the motor and pump head Please make sure the customer is not wiring the M9253f into the U.S. products existing circuit board. The original motor used in U.S. Products is a 90 volt motor installed with a circuit board and speed control, if the Ametek motor is installed utilizing this circuit board will fail. The US Products circuit board and speed control will need to be removed and rectifier installed if being used as a replacement for the original motor. Optional Pumptec Kit, Base Mounting Plate / Bracket For M20/M53/M54 Motors Optional Bridge Rectifier for Edic, PumpTec, Burnishers, & More This is required to make this motor work! Optional: Pumptec: Repair Kit "C" Cam Bearing for 400-500 Psi Models 204V, 205V, 207V, 217V .085 Stroke Replaces 0100-6005-0095 motor does may not be run without a suitable bridge rectifier this motor is often used with the following pump heads Series 205V, 207V, 217V Although these same heads are often used with other motors as well Motor 8-3/4" (includes length of cooling fan) X 3-1/4 motor diameter but cooling fan Diameter is 4" The shaft is not included in this measurement.
